テスト結果の展開と表示

Generate a JUnit.xml file from your tests.

The general file structure should look something like this:

<?xml version="1.0" encoding="UTF-8"?>
<testsuites time="15.682687">
    <testsuite name="Tests.Registration" time="6.605871">
        <testcase name="testCase1" classname="Tests.Registration" time="2.113871" />
    </testsuite>
</testsuites>

Add a <properties> element to associate an attachment with a testcase.

The name attribute of the element must be set with a value attachment_# where # is the ordered index of the attachment file, and the value is the filename. Bitrise will show attachments for any test with the attachment properties, but it's most common to only attach screenshots to failed tests. Mark a test as failed with a <failure> element.

<testcase name="testCase1" classname="Tests.Registration" time="2.113871" />
  <failure message="Assertion error message" type="AssertionError">
    Call stack printed here
  </failure>
  <properties>
    <property name="attachment_1" value="pp1.jpg" />
    <property name="attachment_2" value="pp2.jpg" />
  </properties>
</testcase>

を追加 custom-test-results-export Bitrise ワークフローにステップアップしてください。バージョン 1.1.0 以降である必要があります

workflows:
  inline_attachment:
    steps:
    - generate-text-file:
        inputs:
        - file_name: junit.xml
        - file_content: "xml content with references to image files here"
    - custom-test-results-export:

にテスト名を設定します test_name 入力。

- custom-test-results-export@1:
    inputs:
    - test_name: example_tests

JUnit XML ファイルへのパスを以下に設定します。 search_pattern 入力。

- custom-test-results-export@1:
    inputs:
    - test_name: example_tests
    - search_pattern: junit.xml

を追加 deploy-to-bitrise-io ワークフローの最後まで進んでください。

デフォルトの入力値を変更する必要はありません。設定 YAML ファイル内のワークフロー全体は次のようになります

workflows:
  inline_attachment:
    steps:
    - generate-text-file@0:
        inputs:
        - file_name: junit.xml
        - file_content: "xml content with references to image files here"
    - custom-test-results-export@1:
        inputs:
        - test_name: example_tests
        - base_path: "."
        - search_pattern: junit.xml
    - script@1:
        inputs:
        - content: |
            #!/usr/bin/env bash
            set -ex
            set -o pipefail

            TEST_RESULTS_DIR=$(find "$BITRISE_TEST_DEPLOY_DIR" -type d -name "example_tests" -print -quit)
            cp ~/*.jpg $TEST_RESULTS_DIR
        title: Copy image files to test directory
    - deploy-to-bitrise-io@2: {}
